The power of 5G connectivity, network management, and SDWAN optimization in a compact device that installs in minutes

edge-ant

Compact & Integrated 5G Network System

K4 Edge - High Throughput

The power of 5G connectivity, network management, and SDWAN optimization in a compact device that installs in minutes

Integrated 5G 4x4 Antenna Array, 5G Modem, 2x2 WiFi, GPS, and Network Router

8 SIM cards - manual or automatic selection optimized with K4 Mobility Management

Runs K4 Mobility’s full suite of network controls

Simple to install - 1 ethernet cable with Power over Ethernet (PoE) or +12V DC powered

Location Aware - Always On Connectivity with Global Coverage

Specifications

edge-antcc
EdgeAntenna 5G Front View
edge-antca
EdgeAntenna 5G Back View
Antenna Systems 4×4 OmniDirectional 5G/LTE Cellular Antenna array, 2×2 WiFi, powered GPS
Cellular Modem 5G modem / Cat 20 LTE fallback – 4000 Mbps DL / 660 Mbps UL peak
SIM Bank SIM bank: 8x 2FF(Mini) SIM Slots
WiFi 802.11 ac/a/b/g/n 2×2 MIMO, 1166 Mbps – configurable as Client or AP
GNSS / Navigation GPS, GLONASS, Galileo, BeiDou – with logging and carrier awareness
Network Configurability 500 Clients, 30 VLAN Networks, Stateful Firewall
LAN Interface 1x 1000 Mbps RJ45 with PoE+
Power +12VDC (30W Max); Power over Ethernet (PoE+, 802.3at)
Physical 12.5” (d) x 11.85”(h) / 317.5mm x 301mm : 5 lbs / 2.27 kgs
Environmental Operating temp: 0 to +50 C; Humidity up to 90%, non-condensing
Warranty 1 year limited
>
